DF Smart mist cannon

The Dust Fighter DF Smart is the smallest dust control unit of the Dust Fighter range for outdoor jobs. Extremely light and easily portable, it can be used in a lot of different application fields on small working areas.

Standard Equipment

  • Wheels and handles for transport
  • Stainless steel crown with nozzles
  • Water inlet filter
  • Emergency stop button
  • Tilting system

DF Smart

Electrical engine Single phase 230 V 50 Hz – 2,2 kW
Electrical connection 2 P+T socket – 16 A – IP 67
Water connection Express type 1/2” quick connection
Fan 9 nylon blades, aluminium hub
Air flow 90 mc/min
Coverage (*without wind) 13 mt*
Nozzles holder Stainless steel with 12 connection
Nominal pressure 1 to 5 bar
Water filter 300 microns
Tilting range From 10° to 50°
Dimensions 985 x 785 x 835 (L x W x H mm)
Weight 79 Kg
Water consumption 1.0 bar – 5.4 L/min
1.5 bar – 6.6 L/min
2.0 bar – 7.5 L/min
2.5 bar – 8.5 L/min
DF Smart

Information

  • Mining
  • Demolition
  • Environmentally Friendly
